Image Window Accelerators

Ctrl+A

Opens the Image Window Properties page of the General Properties.

Ctrl+C

Copies the current image to the Windows clipboard.

Ctrl+Shift+C

Copies the marker set (apertures, lines, etc.) from the image to the Windows clipboard.

Ctrl+D

Switches between Roam mode and Cursor command mode. This command switches from any mode into Cursor mode, or from Cursor mode to Roam mode.

Ctrl+E

Executes the Edit Pixel Values command to view a table of pixels as text values.

Ctrl+G

Executes the Go To Coordinates command.

Ctrl+I

Executes the Image Set Properties command for examining or reordering the image set.

Ctrl+N

Executes the New command, which displays the New Document dialog.

Ctrl+O

Executes the File > Open command, which displays the Open dialog.

Ctrl+P

Prints the image.

Ctrl+Q

Shows or hides the Image Set Toolbar.

Ctrl+R

Opens the General Properties. Here you can set global Properties for working with images and plots, as well as other aspects of the user interface.

Ctrl+S

Executes the File > Save command.

Ctrl+T

Opens the Transfer Function Pane dialog.

Ctrl+V

Pastes the current image from the Windows clipboard to the image set position after the currently displayed image. This command works only in conjunction with the Copy (Ctrl+C) command in Mira.

Ctrl+Shift+V

Pastes the marker set from the Window clipboard into the window.

Ctrl+W

Copies the window interior as a bitmap from the screen to the Windows clipboard.

Ctrl+X

Cuts the region outlined by the image cursor by executing the Crop at Cursor command.

Ctrl+Z

Executes the Undo command for the image or image set, as controlled by the Process Image Set flag.

Single Keystroke Commands for the Image Window

a

performs Alignment of the images set by computing a centroid position on the point near the center of the image cursor. The alignment uses horizontal and vertical translation. This works best when the images are already within about 10 pixels of alignment.

c

measures the Centroid position near the center of the image cursor.

h

creates a Row Profile Plot (horizontal plot) of the row centered on the image cursor.

i

creates a Histogram Plot of the region inside the image cursor area.

p

opens or closes the Pixel Table showing values around the center of the cursor. Right click on the pixel table to see its options. The pixel table updates when you wither move the image cursor or cycles between the images of an image set.

r

plots a Radial Profile around the centroid position near the center of the image cursor.

s

calculates Statistics for all pixels inside the image cursor. The type of statistic is selected in the Statistics Properties dialog described above.

v

creates a Column Profile Plot (verical plot) of the column centered on the image cursor.

+

magnifies the image 2 times, centered on the Image Cursor. This also operates from the shifted + key (the = key).

–

de-magnifies the image by 2 times, centered on the Image Cursor. This also operates from the shifted — key (the _ key).

[Shift] + Mouse click

Moves the image cursor to the target point, regardless of the current command mode.

[Tab]

Advances to the next member of the image set.

[Shift] + [Tab]

Steps backward to the previous member of the image set.

Arrow Keys

Move the image cursor precisely on the image, regardless of the current command mode.
