Vertical Slice Plot

This Image Window feature shows a dynamic vertical slice plot for the column through the center of the Image Cursor. As the cursor is moved or the image zoomed or panned, the plot updates. This docking pane can be attached to the left or right window border or stacked on other similarly docked panes, but it cannot be floated outside its parent Image Window. To change the plot properties, right-click inside the pane.

• Open the Vertical Slice Plot pane using the button on the Docking Panes Toolbar.

Related Topics

Horizontal Slice Plot,Docking Panes, Image Windows, User Interface
